2LG810-7AH27 7.5kW High-Pressure Blower
2LG810-7AH27 7.5kW High-Pressure Blower
SPA Whirlpool Application Solution
The 2LG810-7AH27 is a 7.5kW single-impeller high-pressure ring blower (Side Channel Blower). Utilizing a high-pressure regenerative impeller design, it continuously provides stable, clean, oil-free compressed air, widely used in large SPA whiskers, hydrotherapy pools, hot spring pools, water parks, and commercial swimming pool bubble massage systems.
This model features high airflow, high pressure, low noise, and maintenance-free operation. It continuously supplies air to multiple bubble nozzles, creating a uniform and comfortable massage effect. Typical parameters for this model include: maximum airflow approximately 530 m³/h, maximum pressure 430 mbar, maximum vacuum -320 mbar, and a total weight of approximately 66 kg.
Working Principle
The blower uses a high-speed rotating impeller to accelerate and pressurize the air multiple times within the side channel.
After compression, the air enters the bubble channel at the bottom of the whisker, where it is then evenly released into a large number of microbubbles through the bubble nozzles. A large amount of air enters the water, creating:
bubble massage, water circulation, water turbulence, and oxygen-enriching effect.
The entire process requires no lubricant, therefore it does not pollute the water.
Technical Parameters
Item Parameters
Model 2LG810-7AH27
Power 7.5 kW (10 HP)
Voltage Three-phase 380V / 50Hz
Maximum Airflow 530 m³/h
Maximum Pressure 430 mbar
Maximum Vacuum -320 mbar
Noise Approx. 70 dB(A)
Protection Rating IP54/IP55 ( )
Insulation Class F
Weight Approx. 66 kg
Operating Mode Continuous Operation (S1)
Inlet/Outlet G2½"
Applications in Jacuzzis
Suitable for:
Large SPA Jacuzzis
Commercial Jacuzzis
Hotel SPA
Hot Spring Pools
Spa Centers
Water Park Jacuzzis
Health and Wellness Centers
Large Jacuzzis in Villas
Connectable to:
Bottom Bubble Disc
Bubble Massage Nozzles
Spa Nozzles
Air Distributor
Air Bed
Underwater Massage System
Product Features ① **High Airflow Output:**
Maximum airflow of 530 m³/h, capable of simultaneously driving numerous bubble nozzles to meet the uniform air supply needs of large massage pools.
**High Pressure Performance:**
Maximum pressure of 430 mbar, overcoming resistance in deep water and long pipelines, ensuring sufficient airflow even at distant nozzles.
**100% Oil-Free Air:**
Utilizes oil-free compression technology, preventing water pollution.
Especially suitable for:
SPA, Swimming Pools, Hot Springs, Spa Equipment
Meets hygiene requirements.
**24-Hour Continuous Operation:** Employs industrial-grade bearings and a high-efficiency heat dissipation structure, allowing for long-term continuous operation, suitable for all-weather use in hotels and commercial spas.
**Low Noise Design:**
The fan operates smoothly with minimal vibration and noise (approximately 70 dB). A silencer can be added to further reduce operating noise.
**Easy Installation:**
Supports:
Horizontal Installation
Vertical Installation
Compact structure, small footprint.
**7** Maintenance-Free
Utilizing:
Brushless
Beltless
Gearless
Lubricant-free
Normal use requires only periodic filter cleaning.
⑧ High Reliability
Aluminum alloy die-cast housing
Precision dynamically balanced impeller
High-quality bearings
Corrosion-resistant design
Suitable for long-term operation in humid environments.
Product Advantages
✅ More stable airflow than traditional vortex blowers
✅ Lower noise than Roots blowers
✅ More energy-efficient than air compressors
✅ Cleaner oil-free air
✅ Can operate continuously for 24 hours
✅ Simple installation and low maintenance costs
✅ Long service life
Application Advantages
Using the 2LG810-7AH27 as a SPA bubble blower can achieve:
Richer massage bubble effects
More even bubble distribution
A more comfortable spa experience
Higher water oxygen content
Better circulation
Reduced overall operating energy consumption
