S Type Strain Gauge Force Load Cell
Brand SOP
Product origin China
Delivery time 2days
Supply capacity 300 pcs/day
1. Available in capacities from 0 to 20,000 lbs and 0 to 10,000 kg
2. Alloy steel, sealed by adhesive inside, oil-proof, waterproof and anti-corrosion, suitable for all kinds of environments.
3. S beam design, tension and/or compression loading possible, easy installation, suitable for crane scale, mechanical conversion scale, hopper scale and other electronic weighing devices.
4. Provided with a certificate of conformance and full-scale calibration.
S Type Strain Gauge Force Load Cell
Analog Sensor Output S Type Alloy Steel Load Cell
Specification
Capacity | 0.2~5T |
Rated Output | 2.0mV/V |
Zero Balance | ±1% F.S. |
Non-linearity | 0.03%F.S. |
Hysteresis | 0.03%F.S. |
Repeatability | 0.03%F.S. |
Creep(30min) | 0.03%F.S. |
Temp.effect on output | 0.03% F.S. / 10ºC |
Temp.effect on zero | 0.03% F.S. / 10ºC |
Material | Alloy steel |
Operating Voltage Range | 5-15V |
Operating Temp Range | -20-80℃ |
Safe overload | 150% |
Maximum Overload | 200% |
Cable size | 0.2~1t: Φ5*:2m, 2-5t: Φ5*:5m |
Cable ultimate pull | 10kg |
Deatil Pictures
Factory Show
FAQ
Q1:How do you control the quality?
A: We have QC team comply with TQM,each step is in compliance to the standards. At the same time,they will take photos and shoot video for you.
Q2: Can you print our brand on the product?
A: Yes, Of course. It can make customer’s brand logo.
Q3: What is the payment terms?
A: T/T, Western Union, Paypal, Escrow alibaba is acceptable.Escrow is same like paypal, after you place the order and make the payment on alibaba.com, alibaba company will notify us to make the shipment, your money won't be released until you get the goods. If we don't make the shipment, you still can take back your money.
Q4: How long is your warranty period?
A: Our warranty period is 12 months.
Q3: What is the payment terms?
A: T/T, Western Union, Paypal, Escrow alibaba is acceptable.Escrow is same like paypal, after you place the order and make the payment on alibaba.com, alibaba company will notify us to make the shipment, your money won't be released until you get the goods. If we don't make the shipment, you still can take back your money.
Q4: How long is your warranty period?
A: Our warranty period is 12 months.
